UAV Infrared and EL Detection

With the implementation of the policy of carbon neutrality and carbon peak in China, photovoltaic power stations are playing an increasingly important role. In the means of detecting the quality of power stations, photovoltaic UAV, as a more advanced equipment, can meet the detection requirements quickly and efficiently.

Photovoltaic UAV equipment is applied in array module EL detection and thermal imaging detection of photovoltaic power station, with efficient and portable, high-precision detection module can carry out fixed-point or large-area inspection, and a variety of detection functions. The main body uses DJI (M300RTK) industry UAV. As the first market share in the world, DJI UAV has higher flight stability and reliability. M300RTK lightweight design of the fuselage can fly up to 50 minutes. It is equipped with the next generation of accurate and reliable A3 flight control system and LIGHTBRIDGE 2 HD digital graphics. The modules are installed with shock absorbers designed to ensure reliable flight performance and handling. The built-in flight parameter adaptive function realizes free adjustment of parameters under different loads within the range of 2.5kg, convenient operation. At the same time, the UAV has built-in stability module, which can greatly improve flight reliability, effectively remove the influence of magnetic interference and provide centimeter-level positioning function. The whole system has higher endurance test safety and stability performance.

NOA has rich experience in UAV inspection, and has carried out UAV infrared and EL detection on various types of photovoltaic power stations, such as ground centralized power station, mountain centralized power station, fishery light complementary power station, agricultural light complementary power station or large distributed power station, to check the faults of photovoltaic modules and systems for customers, so as to improve the overall performance of photovoltaic system.

Service Content

1. Service content

1. UAV EL detection

2. Thermal imaging (infrared) detection and inspection

3. Other customized services

2. The introduction of UAV equipment

1. HD EL detection module
Photovoltaic UAV detection equipment is equipped with the world's leading EL frequency scanning camera module, which has the high-definition EL video scanning function of photovoltaic string, and can complete the EL detection of a single string in 12 seconds. With the Lekos string type EL detection power module, it can achieve aerial detection scanning of UAVs, or handheld scanning of EL, or switch to the photography mode for high-definition EL photography, detection and imaging. Its detection advantages are particularly prominent in greenhouses, roofs, and watersurface power stations, The EL video detection module can be configured with multiple functions to meet all the requirements for detection of hidden crack defects in the EL of photovoltaic power plant modules.

2. High resolution thermal imaging module
Photovoltaic UAV detection equipment adopts imported multi-sensor thermal imaging module, and its full radiation infrared detection module of up to 640X512 pixels can realize 30HZ high-definition thermal radiation infrared image and synchronous data recording. The thermal imaging module is equipped with infrared and visible dual image transmission storage function, and powerful thermal imaging analysis software can effectively help with late defect analysis and positioning analysis. The complete set of thermal imaging system is equipped with GPS positioning UAV cruise detection function, which can complete the detection and recording function of a whole array under no man's condition. It can meet all thermal imagining detection needs, including photovoltaic power plant inspection.

Service Process

Q&A

1.Does the UAV test have a clear image?

According to the current data, under the condition of not being affected by air flow, the detection method of UAV is basically consistent with the traditional method of handheld thermal images. It is recommended to use in clear and windless weather conditions.

2.How to control the UAV to do the test?

NOA uses the operating system in the module to program the path of UAV after a field survey of the power station by professional inspection engineers.

3.Is the spot detected by UAV thermal imaging obvious?

NOA used more sensing thermal imaging module, every piece of module can be precise positioning, automatic identified ten kinds of defects.

4.What kind of power station can be inspected by UAV?

In general, all power stations can use drones for inspection, which should be customized according to site conditions. Such as ground centralized power station, mountain centralized power station, fishing light complementary power station, agricultural light complementary power station or large distributed power station, can adopt this advanced technology means. If the module position is on the high side and manual detection is difficult, UAV is the best choice.
