Photovoltaic power generation is a technology that directly converts solar energy into electrical energy using the photovoltaic effect at the interface of semiconductors. The key component of this technology is the solar cell. Solar cells, when connected in series and encapsulated for protection, form large-area solar modules. When combined with components like power controllers, they constitute a photovoltaic power generation system.

(1) Solar cell - Its main function is to generate electricity;

(2) Tabbing ribbon - Its main function is to collect and channel the electricity generated by the solar cells to the junction box;

(3) EVA (Ethylene Vinyl Acetate) - Its main function is to bond and fix tempered glass and the main electricity-generating body, encapsulating the main electricity-generating body and the backsheet;

(4) Tempered glass - Its role is to protect the main electricity-generating body (solar cells);

(5) Backsheet - Its role is to seal, insulate, and waterproof (usually made of materials like TPT, TPE, which must be resistant to aging);

(6) Aluminum alloy frame - It acts as a protective compression part, providing certain sealing and support, enhancing mechanical strength;

(7) Junction box - It protects the entire power generation system and serves as a current transfer station;

(8) Silicone - Used to seal the junction between the module and the aluminum alloy frame, and the junction between the module and the junction box.

The main quality risk point is latent cracks:

(1) Latent cracks may lead to hot spot effects;

(2) They can accelerate the power attenuation of solar cells;

(3) They can affect the normal service life of the module;

(4) Under mechanical loads, they can expand and potentially cause open-circuit damage.

Other quality risk points include: virtual soldering, busbar breaks, light and dark areas, scratches on solar cells, and dark spots.

Main raw and auxiliary materials:

(1) Glass: dimensional accuracy, light transmittance, tempering, impact resistance, appearance;

(2) EVA (Ethylene Vinyl Acetate): dimensional accuracy, shrinkage rate, cross-linking degree, light transmittance after cross-linking, appearance;

(3) Backsheet: dimensional accuracy, interlayer peel strength, appearance;

(4) Busbars & Ribbon: dimensional accuracy, resistivity, elongation, coating melting temperature, tensile strength, appearance;

(5) Junction Box: adhesive strength to the backsheet, connection strength between leads and casing, high/low-temperature mechanical stability, appearance;

(6) Potting compound for junction box, sealing silicone: appearance, surface drying time, curing time, elongation at break;

(7) Aluminum frame: Vickers hardness, dimensions, riveting static load, appearance.
